D-Link DWL-8610AP User Manual

Captive Portal Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 385
D-Link UWS User Manual
The following table describes the global CP fields you can view or configure.
Table 223: Captive Portal Global Configuration
Field Description
Enable Captive
Portal
Select the check box to enable the CP feature on the switch. Clear the check box to
disable the captive portal feature.
CP Global
Operational Status
Shows whether the CP feature is enabled.
CP Global Disable
Reason
If CP is disabled, this field displays the reason, which can be one of the following:
• None
• Administratively Disabled
• No IPv4 Address
• Routing Enabled, but no IPv4 routing interface
Additional HTTP
Port
HTTP traffic uses port 80, but you can configure an additional port for HTTP traffic. Enter
a port number between 0-65535 (excluding ports 80, 443, and the configured switch
management secure port).
Additional HTTP
Secure Port
HTTP traffic over SSL (HTTPS) uses port 443, but you can configure an additional port for
HTTPS traffic. Enter a port number between 0-65535 (excluding ports 80, 443, and the
configured switch management secure port).
Peer Switch
Statistics Reporting
Interval
When clustering is supported on the switch, enter a value to determine how often the
switch sends its authenticated client statistics to the Cluster Controller. The interval is in
seconds. Enter a value of 0 to prevent the switch from reporting the statistics.
Authentication
Timeout
To access the network through a portal, the wireless client must first enter
authentication information on an authentication Web page. Enter the number of
seconds to keep the authentication session open with the client. When the timeout
expires, the switch disconnects any active TCP or SSL connection with the client.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
