D-Link DWL-8610AP User Manual

Configuring Dynamic ARP Inspection
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 276
D-Link UWS User Manual
DAI Interface Configuration
Use the DAI Interface Configuration page to select the DAI Interface for which information is to be displayed
or configured.
To display the DAI Interface Configuration page, click LAN > L2 Features>Dynamic ARP Inspection > DAI
Interface Configuration in the navigation tree.
Figure 173: Dynamic ARP Inspection Interface Configuration
• Click Submit to apply the new configuration and cause the change to take effect. These changes will not
be retained across a power cycle unless a Save configuration is performed.
• Click Refresh to refresh the page with the most current data from the switch.
Table 156: Dynamic ARP Inspection Interface Configuration
Field Description
Interface Select the physical interface for which data is to be displayed or configured.
Trust State Indicates whether the interface is trusted for Dynamic ARP Inspection. If you select Enable,
the interface is trusted. ARP packets coming to this interface will be forwarded without
checking. If you select Disable, the interface is not trusted. ARP packets coming to this
interface will be subjected to ARP inspection. The default is Disable.
Rate Limit Specifies rate limit value for Dynamic ARP Inspection purpose. If the incoming rate of ARP
packets exceeds the value of this object for consecutively burst interval seconds, ARP
packets will be dropped. If this value is -1 there is no limit. The Range is (0 to 300 pps). The
factory default is 15pps (packets per second).
No Limit Selecting this option specifies that the value of Rate Limit will be configured to -1. If the
rate limit is -1 burst interval has no meaning , hence it is disabled.
Burst Interval Specify the burst interval for rate limiting on this interface. If the Rate Limit is None, then
Burst Interval has no meaning and shows as N/A (Not Applicable). The default is 1 second.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
