D-Link DWL-8610AP User Manual

Managing and Viewing Logs
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 124
D-Link UWS User Manual
Trap Log
Use the Trap Log page to view the entries in the trap log. For information about how to copy the file to a TFTP
server, see “Upload File From Switch (TFTP)” on page 175.
To access the Trap Log page, click LAN > Monitoring > Log > Trap Log in the navigation menu.
Figure 51: Trap Log
• Click Clear Log to clear all entries in the log. Subsequent displays of the log will only show new log entries.
Table 43: Trap Log Fields
Field Description
Number of Traps Since Last
Reset
The number of traps generated since the trap log entries were last cleared.
Trap Log Capacity The maximum number of traps stored in the log. If the number of traps
exceeds the capacity, the entries will overwrite the oldest entries.
Number of Traps Since Log
Last Viewed
The number of traps that have occurred since the traps were last displayed.
Displaying the traps by any method (terminal interface display, Web display,
upload file from switch, etc.) will cause this counter to be cleared to 0.
Log The sequence number of this trap.
System Up Time The time at which this trap occurred, expressed in days, hours, minutes and
seconds since the last reboot of the switch.
Trap Displays the information identifying the trap.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
