D-Link DWL-8610AP User Manual

Managing LLDP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 259
D-Link UWS User Manual
Global Configuration
Use the LLDP Global Configuration page to specify LLDP parameters that are applied to the switch.
To display the LLDP Global Configuration page, click LAN > L2 Features > LLDP > Global Configuration in the
navigation tree.
Figure 158: LLDP Global Configuration
• If you make any changes to the page, click Submit to apply the new settings to the system.
Table 141: LLDP Global Configuration Fields
Field Description
Transmit Interval Specifies the interval at which LLDP frames are transmitted. The default is 30
seconds, and the valid range is 5-32768 seconds.
Transmit Hold Multiplier Specifies multiplier on the transmit interval to assign to TTL. The default is 4,
and the range is 2-10.
Re-Initialization Delay Specifies the delay before a re-initialization. The default is 2 seconds, and the
range is 1-10 seconds.
Notification Interval Limits the transmission of notifications. The default is 5 seconds, and the
range is 5-3600 seconds.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
