D-Link DWL-8610AP User Manual

Managing and Viewing Logs
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 115
D-Link UWS User Manual
Viewing Buffered Log Messages
Use the Buffered Log page to view the log messages in the system buffer. The newest messages are displayed
at the bottom of the page.
To access the Buffered Log page, click LAN > Monitoring > Log > Buffered Log in the navigation menu.
Figure 42: Buffered Log
The rest of the page displays the buffered log messages. The following example shows a log message:
<15>Aug 24 05:34:05 STK0 M[2110]: mspt_api.c(318) 237 %% Interface 12 transitioned to root state on
message age timer expiry
This log message has a severity level of 7 (15 mod 8), which is a debug message. The system is not stacked
(STK0). The message was generated by the M component running in thread ID 2110. The message was
generated on August 24 05:34:05 by line 318 of file m_api.c. This is the 237
th
message logged.
• Click Refresh to update the page with the latest messages.
Table 36: Buffered Log Fields
Field Description
Total Number of Messages Shows the number of buffered messages the system has logged. Only the 128
most recent entries are displayed on the page.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
