D-Link DWL-8610AP User Manual

AutoInstall
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 180
D-Link UWS User Manual
Click Submit to update the switch with the values on the window. Click Refresh to update the information on
the window.
Table 79: AutoInstall Fields
Field Description
AutoInstall Mode • Select Start to initiate sending a request to a DHCP server to obtain an IP address of a
server and the configuration file name. If it obtains the server address, AutoInstall
proceeds to search for and download a configuration file from the server. If successful,
it applies the configuration file to the switch. After starting the AutoInstall process, you
can monitor the status of the process by the messages in the AutoInstall State and
Retry Count fields.
• Click Stop to end the process.
AutoSave Mode Enable or Disable saving the network configuration to non-volatile memory. When
enabled, the configuration is saved after downloading from the TFTP server without
operator intervention. When disabled, the operator must explicitly save the configuration,
if needed.
Retry Count The number of times the switch has attempted to contact the TFTP server during the
current AutoInstall session.
AutoInstall State The status of the current or most recently completed AutoInstall session.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
