Locating WLAN Devices
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 657
D-Link UWS User Manual
The following table shows the fields available on the On-Demand Location Trigger Global Status page.
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Table 379: On-Demand Location Trigger Global Status
Field Description
Type of Device Indicates whether the most recent On-Demand Location process was
invoked to find an AP or a Client.
Device MAC AP or Client MAC address whose location was requested.
Building Number Number that identifies the building that was searched for the device.
Floor Number Number that identifies the floor of the building that was searched for
the device.
Use Operational Mode Radios Indicates whether the network used only sentry radios or both sentry
and operational mode radios to perform the search.
Location Procedure Status Identifies the current status of the On-Demand Location procedure:
• Not Started
• In Progress
• Device Located
• Device is not located
• No APs Available for Locating Device
Time Since Device-Location Triggered Amount of time in days, hours, minutes, and seconds that has passed
since the search was initiated. If the on-demand device location was
never triggered, the time stamp is 0d 00:00:00
Number of Locator APs Number of managed APs that participated in the search.
Number of Detecting APs Number of managed APs that detected the device.
Number of Buildings with Detected
Signal
Number of buildings where managed APs detected the target device.
Number of Floors with Detected
Signal
Number of building floors where managed APs detected the target
device. Floors from different buildings may be included in this status.
Building with the Highest Detected
Signal
Building number in which the target device was detected by a
managed AP with the highest RSSI.
Floor with the Highest Detected
Signal
Floor number on which the target device was detected by a managed
AP with the highest RSSI.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
