D-Link DWL-8610AP User Manual

Managing and Viewing Logs
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 116
D-Link UWS User Manual
Command Logger Configuration
Use the Command Logger Configuration page to enable the system to log all CLI commands issued on the
system. The command log messages are interleaved with the other system logs messages.
To access the Command Logger Configuration page, click LAN > Administration > Log > Command Logger
Configuration in the navigation menu.
Figure 43: Command Logger Configuration
• If you change the administrative mode, click Submit to apply the change to the system.
Table 37: Command Logger Configuration Fields
Field Description
Admin Mode This field determines whether to log CLI commands in the system log file.
• Enable: The system logs CLI commands. The commands appear in
messages on the Buffered Log page. For example, the following log
messages shows when the CLI command
show logging buffered was
issued, from which IP address the command was issued, and the name of
the user who issued the command:
<5> NOV 29 22:25:00 10.254.24.172-1 UNKN[243420816]:
cmd_logger_api.c(87) 34 %% CLI:10.254.24.65:admin:show
logging buffered
• Disable: This system does not log CLI commands.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
