D-Link DWL-8610AP User Manual

Configuring and Viewing Device Port Information
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 113
D-Link UWS User Manual
Port Description
Use the Port Description page to configure a human-readable description of the port.
To access the Port Description page, click LAN > Administration > Port Configuration > Port Description in the
navigation tree.
Figure 40: Port Description
• If you change a port description, click Submit to apply the change to the system.
• Click Refresh to display the page with the latest information from the router.
Table 35: Port Description Fields
Field Description
Slot/Port Select the interface for which data is to be displayed or configured.
Port Description Enter text to describe a port. It can be up to 64 characters in length. The
description can contain spaces and non-alphanumeric characters.
Slot/Port Identifies the port.
Physical Address Displays the physical address of the specified interface.
PortList Bit Offset Displays the bit offset value which corresponds to the port when the MIB
object type PortList is used to manage in SNMP.
IfIndex Displays the interface index associated with the port.
Port Description Shows the configured port description. By default, the port does not have an
associated description.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
