Configuring DNS
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 146
D-Link UWS User Manual
• To create a new list of domain names, click Create. Then enter a name of the list and click submit. Repeat
this step to add multiple domains to the default domain list.
• To remove a domain from the default list select the Remove option next to the item you want to remove
and click Submit.
Server Configuration
Use this page to configure information about DNS servers that the router will use. The order in which you
create them determines their precedence; i.e., DNS requests will go to the higher precedence server first. If
that server is unavailable or does not respond in the configured response time, then the request goes to the
server with the next highest precedence.
To access this page, click LAN > Administration >DNS Client > Server Configuration.
Figure 67: DNS Server Configuration
• To create a new DNS server, enter an IP address in standard IPv4 or IPv6 dot notation in the DNS Server
Address and click Submit. The server appears in the list below. The precedence is set in the order created.
• To change precedence, you must remove the server(s) by clicking the Remove box and then Submit, and
add the server(s) in the preferred order.
Table 59: DNS Server Configuration Fields
Field Description
DNS Server Address To add a new DNS server to the list, enter the DNS server IPv4 or IPv6 address
in numeric notation.
Precedence Shows the precedence value of the server that determines which server is
contacted first; a lower number indicates has higher precedence.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
