D-Link DWL-8610AP User Manual

Secure Shell (SSH) Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 382
D-Link UWS User Manual
Secure Shell (SSH) Configuration
If you use the command-line interface (CLI) to manage the switch from a remote system, you can use Secure
Shell (SSH) to establish a secure connection. SSH uses public-key cryptography to authenticate the remote
computer.
Secure Shell Configuration
Use the Secure Shell Configuration page to configure the settings for secure command-line based
communication between the management station and the switch.
To display the Secure Shell Configuration page, click LAN > Security > Secure Shell > SSH Configuration in the
navigation menu.
Figure 258: Secure Shell Configuration
Table 222: Secure Shell Configuration Fields
Field Description
Admin Mode This select field is used to Enable or Disable the administrative mode of SSH.
The currently configured value is shown when the web page is displayed. The
default value is Disable.
SSH Version 1 This select field is used to Enable or Disable Protocol Level 1 for SSH. The
currently configured value is shown when the web page is displayed. The
default value is Enable.
SSH Version 2 This select field is used to Enable or Disable Protocol Level 2 for SSH. The
currently configured value is shown when the web page is displayed. The
default value is Enable.
SSH Connections in Use Displays the number of SSH connections currently in use in the system.
Maximum Number of SSH
Sessions Allowed
This select field is used to configure the maximum number of inbound SSH
sessions allowed on the switch. The currently configured value is shown when
the web page is displayed. The range of acceptable values for this field is (0-5).

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
