D-Link DWL-8610AP User Manual

Configuring Port Security
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 376
D-Link UWS User Manual
Port Security Static
Use the Port Security Static page to view static MAC addresses configured on an interface.
To access the Port Security Static page, click LAN > Security > Port Security Static in the navigation tree.
Figure 253: Port Security Static
• After you enter the MAC address and VLAN ID of the statically configured MAC address to delete, click
Submit to remove the MAC address from the port and apply the new settings to the system. The screen
refreshes, and the MAC address no longer appears in the table on the page.
Table 218: Port Security Static Fields
Field Description
Interface Select the physical interface or the LAG on which to view the dynamically learned MAC
addresses.
MAC Address This column lists the static MAC addresses, if any, configured on the selected port.
VLAN ID Displays the VLAN ID corresponding to the statically configured MAC address.
Delete a static
MAC Address
Enter the address of the statically configured MAC address to delete. All MAC addresses
that are available to be deleted appear in the MAC Address – VLAN ID table.
VLAN ID Enter the VLAN ID that corresponds to the statically configured MAC address to delete.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
