D-Link DWL-8610AP User Manual

Configuring Dynamic ARP Inspection
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 278
D-Link UWS User Manual
DAI ARP ACL Rule Configuration
Use the DAI ARP ACL Rule Configuration page to add or remove DAI ARP ACL Rules.
To display the DAI ARP ACL Rule Configuration page, click LAN > L2 Features>Dynamic ARP Inspection > DAI
ARP ACL Rule Configuration in the navigation tree.
Figure 175: Dynamic ARP Inspection ARP ACL Rule Configuration
• Click Add to add a new ARP ACL rule.
• Click Submit to delete the entries selected in the Remove column.
• Click Refresh to refresh the page with the most current data from the switch.
Table 158: Dynamic ARP Inspection ARP ACL Rule Configuration
Field Description
ARP ACL Name Select the ARP ACL for which information is to be displayed or configured.
Sender IP Address To create a new rule for the selected ARP ACL, enter in this field the Sender IP Address
match value for the ARP ACL.
Sender MAC
Address
To create a new rule for the selected ARP ACL, enter in this field the Sender MAC Address
match value for the ARP ACL.
Remove Use the Remove column to select the particular ARP ACL Rules you want to delete.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
