D-Link DWL-8610AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 521
D-Link UWS User Manual
Figure 342: WIDS Client Rogue Classification
The following table shows information about the security test performed on the detected client.
Command Buttons
The page includes the following button:
Table 310: WIDS Client Rogue Classification
Field Description
MAC Address The Ethernet MAC address of the detected wireless client.
Test Description Identifies the tests that were performed, which includes the following:
• Client is denied access in the Known Client Database.
• Client exceeds the configured rate for transmitting 802.11 authentication
requests.
• Client exceeds the configured rate for transmitting probe requests.
• Client exceeds the configured rate for transmitting de-authentication requests.
• Client exceeds the maximum number of failing authentications.
• Known Client is authenticated with an Unknown AP.
• Client OUI is not in the OUI Database
Condition Detected Indicates whether the result of the test was true or false.
Reporting MAC
Address
Identifies the MAC address of the AP that reported the test results.
Radio Identifies which physical radio on the reporting AP was responsible for the test
results.
Test Config Shows whether this test is configured to report rogues. Each test can be globally
enabled or disabled to report a positive result as a rogue.
Test Result Shows whether this test reported the device as rogue. In some cases the test may
report a positive result, be enabled, but not report the device as rogue because the
device is allowed to operate in this mode.
Time Since First Report Time stamp indicating how long ago this test first detected the condition.
Time Since Last Report Time stamp indicating how long ago this test last detected the condition.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
