D-Link DWL-8610AP User Manual

System Description
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 63
D-Link UWS User Manual
System Description
After a successful login, the System Description page displays. Use this page to configure and view general
device information.
To display the System Description page, click LAN > Administration > System Description in the navigation
tree.
Figure 7: System Description
Table 3: System Description Fields
Field Description
System Description The product name of this switch.
System Name Enter the name you want to use to identify this switch. You may use up to 31 alpha-
numeric characters. The factory default is blank.
System Location Enter the location of this switch. You may use up to 31 alpha-numeric characters. The
factory default is blank.
System Contact Enter the contact person for this switch. You may use up to 31 alpha-numeric
characters. The factory default is blank.
IP Address The IP Address assigned to the network interface. To change the IP address, see
“Serial Port” on page 73.
System Object ID The base object ID for the switch's enterprise MIB.
System Time (yyyy-
mm-dd h:m:s)
Enter the current date and time that the switch will follow using the on-board real-
time clock.
System Up Time Displays the number of days, hours, and minutes since the last system restart.
Current SNTP
Synchronized Time
Displays currently synchronized SNTP time in UTC. If no SNTP server has been
configured and the time is not synchronized, this field displays “Not Synchronized.”
To specify an SNTP server, see “Configuring SNTP Settings” on page 97.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
