D-Link DWL-8610AP User Manual

Managing and Viewing Logs
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 123
D-Link UWS User Manual
Syslog Configuration
Use the Syslog Configuration page to allow the switch to send log messages to the remote logging hosts
configured on the system.
To access the System Log Configuration page, click LAN > Administration > Log > System Log Configuration in
the navigation tree.
Figure 50: System Log
• If you make any changes to the page, click Submit to apply the change to the system.
Table 42: Syslog Configuration Fields
Field Description
Admin Status Specifies whether to send log messages to the remote syslog hosts configured on the
switch:
• Enable: Messages will be sent to all configured hosts (syslog collectors or relays)
using the values configured for each host. For information about syslog host
configuration, see “Hosts Configuration” on page 119.
• Disable: Stops logging to all syslog hosts. Disable means no messages will be sent
to any collector/relay.
Local UDP Port Specifies the port on the switch from which syslog messages are sent. The default
port is 514.
Messages Received The number of messages received by the log process. This includes messages that are
dropped or ignored.
Messages Dropped The number of messages that could not be processed due to error or lack of
resources.
Messages Relayed The number of messages forwarded by the syslog function to a syslog host. Messages
forwarded to multiple hosts are counted once for each host.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
