Command Buttons
The page includes the following buttons:
• Refresh—Updates the page with the latest information.
• Clear Statistics—Reset all counters on the page to zero.
Viewing Switch Status and Statistics Information
The Switch Status/Statistics page for each switch provides information about the access points it manages and
their associated clients. If the switch is the Cluster Controller, it provides the switch status and statics
information about each switch in its group.
Use the drop-down menu to select the switch with the information to display. If the local switch is the only
available option, then it is the only switch in the cluster, or it is not a Cluster Controller.
TSPEC Statistics (Voice and Video)
Total TSPEC Packets
Received
The number of TSPEC packets sent from the wireless client to the AP. The number is
a total for all APs managed by the switch.
Total TSPEC Packets
Transmitted
The number of TSPEC packets sent from the AP to the wireless client. The number is
a total for all APs managed by the switch.
Total TSPEC Bytes
Received
The number of TSPEC bytes sent from the wireless client to the AP. The number is a
total for all APs managed by the switch.
Total TSPEC Bytes
Transmitted
The number of TSPEC bytes sent from the AP to the wireless client. The number is a
total for all APs managed by the switch.
Total TSPECs Accepted The number of TSPEC packets that were accepted by all APs that the switch manages.
Total TSPECs Rejected The number of TSPEC packets that were rejected by all APs that the switch manages.
Total Roaming TSPECs
Accepted
The total number of TSPEC packets transmitted by roaming clients that were
accepted by all APs that the switch manages.
Total Roaming TSPECs
Rejected
The total number of TSPEC packets transmitted by roaming clients that were
rejected by all APs that the switch manages.
Note: Only the Cluster Controller switch can display managed APs, clients, statistics, and RF Scan
database information for the whole cluster. The switches that are not Cluster Controllers can display
information about locally attached devices.
Table 258: Global WLAN Status/Statistics (Cont.)
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
