D-Link DWL-8610AP User Manual

Denial of Service Protection
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 89
D-Link UWS User Manual
• If you change any of the DoS settings, click Submit to apply the changes to the switch. To preserve the
changes across a switch reboot, you must perform a save.
Table 18: Denial of Service Configuration Fields
Field Description
Denial of Service First
Fragment
Enable or disable this option by selecting the corresponding line on the
pulldown entry field. Enabling First Fragment DoS prevention causes the
switch to drop packets that have a TCP header smaller then the configured
Min TCP Hdr Size. The factory default is disabled.
Denial of Service Min TCP Hdr
Size
Specify the Min TCP Hdr Size allowed. If First Fragment DoS prevention is
enabled, the switch will drop packets that have a TCP header smaller then this
configured Min TCP Hdr Size. The factory default is disabled.
Denial of Service ICMP Enable or disable this option by selecting the corresponding line on the
pulldown entry field. Enabling ICMP DoS prevention causes the switch to drop
ICMP packets that have a type set to ECHO_REQ (ping) and a size greater than
the configured ICMP Pkt Size. The factory default is disabled.
Denial of Service Max ICMP
Size
Specify the Max ICMP Pkt Size allowed. If ICMP DoS prevention is enabled, the
switch will drop ICMP ping packets that have a size greater than this
configured Max ICMP Pkt Size. The factory default is disabled.
Denial of Service L4 Port Enable or disable this option by selecting the corresponding line on the
pulldown entry field. Enabling L4 Port DoS prevention causes the switch to
drop packets that have TCP/UDP source port equal to TCP/UDP destination
port. The factory default is disabled.
Denial of Service SIP=DIP Enable or disable this option by selecting the corresponding line on the
pulldown entry field. Enabling SIP=DIP DoS prevention causes the switch to
drop packets that have a source IP address equal to the destination IP address.
The factory default is disabled.
Denial of Service TCP Flag Enable or disable this option by selecting the corresponding line on the
pulldown entry field. Enabling TCP Flag DoS prevention causes the switch to
drop packets that have TCP flag SYN set and TCP source port less than 1024 or
TCP control flags set to 0 and TCP sequence number set to 0 or TCP flags FIN,
URG, and PSH set and TCP sequence number set to 0 or both TCP flags SYN and
FIN set. The factory default is disabled.
Denial of Service TCP
Fragment
Enable or disable this option by selecting the corresponding line on the
pulldown entry field. Enabling TCP Fragment DoS prevention causes the
switch to drop packets that have an IP fragment offset equal to 1. The factory
default is disabled.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
