RADIUS Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 417
D-Link UWS User Manual
If at least one RADIUS accounting server is configured on the switch, and a host address is selected in the
Accounting Server Host Address field, then additional fields are available on the Accounting Server
Configuration page.
Figure 287: RADIUS Accounting Server Configuration—Server Added
Use the buttons at the bottom of the page to perform the following actions:
• If you make changes to the page, click Submit to apply the changes to the system.
• To delete a configured RADIUS accounting server, select the IP address of the server from the RADIUS
Server IP Address drop-down menu, and then click Remove.
• Click Refresh to update the page with the most current information.
Table 245: RADIUS Accounting Server Configuration Fields
Field Description
Accounting Server Host
Address
Use the drop-down menu to select the IP address of the accounting server to
view or configure. Select Add to configure additional RADIUS servers.
Port Identifies the authentication port the server uses to verify the RADIUS
accounting server authentication. The port is a UDP port, and the valid range
is 1-65535. The default port for RADIUS accounting is 1813.
Secret Specifies the shared secret to use with the specified accounting server. This
field is only displayed if you are logged into the switch with READWRITE
access.
Apply The Secret will only be applied if this box is checked. If the box is not checked,
anything entered in the Secret field will have no affect and will not be
retained. This field is only displayed if you are logged into the switch with
READWRITE access.
Secret Configured Indicates whether the shared secret for this server has been configured.
RADIUS Accounting Server
Name
Enter the name of the RADIUS accounting server.
The name can contain up to 32 alphanumeric characters. Spaces, hyphens,
and underscores are also permitted. If you do not assign a name, the server is
assigned the default name Default-RADIUS-Server.
You can use the same name for multiple RADIUS accounting servers. RADIUS
clients can use accounting servers with the same name as backups for each
other.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
