Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 482
D-Link UWS User Manual
Viewing Managed Access Point Radio Statistics
The radio statistics show detailed information about the packets and bytes transmitted and received on the
radio (wireless) interface of a particular access point managed by the switch.
Use the options above the table to select the AP and radio with the settings to view. The AP is identified by its
MAC address and location. The radio is identified by its number and configured mode. If the radio is disabled,
the radio mode will be displayed as Off.
Table 282 describes the fields you see on the Radio page for the managed access point statistics.
Table 282: Managed Access Point Radio Statistics
Field Description
WLAN Packets Received Total packets received by the AP on this radio interface.
WLAN Bytes Received Total bytes received by the AP on this radio interface.
WLAN Packets Transmitted Total packets transmitted by the AP on this radio interface.
WLAN Bytes Transmitted Total bytes transmitted by the AP on this radio interface.
WLAN Packets Receive Dropped Number of packets received by the AP on this radio interface that were
dropped.
WLAN Bytes Receive Dropped Number of bytes received by the AP on this radio interface that were
dropped.
WLAN Packets Transmit Dropped Number of packets transmitted by the AP on this radio interface that
were dropped.
WLAN Bytes Transmit Dropped Number of bytes transmitted by the AP on this radio interface that were
dropped.
Fragments Received Count of successfully received MPDU frames of type data or
management.
Fragments Transmitted Number of transmitted MPDU with an individual address or an MPDU
with a multicast address of type Data or Management.
Multicast Frames Received Count of MSDU frames received with the multicast bit set in the
destination MAC address.
Multicast Frames Transmitted Count of successfully transmitted MSDU frames where the multicast bit is
set in the destination MAC address.
Duplicate Frame Count Number of times a frame is received and the Sequence Control field
indicates is a duplicate.
Failed Transmit Count Number of times a MSDU is not transmitted successfully due to transmit
attempts exceeding either the short retry limit or the long retry limit.
Transmit Retry Count Number of times a MSDU is successfully transmitted after one or more
retries.
Multiple Retry Count Number of times a MSDU is successfully transmitted after more than one
retry.
RTS Success Count Count of CTS frames received in response to an RTS frame.
RTS Failure Count Count of CTS frames not received in response to an RTS frame.
ACK Failure Count Count of ACK frames not received when expected.
FCS Error Count Count of FCS errors detected in a received MPDU frame.
