D-Link DWL-8610AP User Manual

Detecting and Preventing Wireless Intrusion
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 734
D-Link UWS User Manual
Mitigating a Rogue Client Threat
In this scenario, the network administrator for a retail store is implementing Rogue Client Threat Mitigation to
provide additional security in her store located in a shopping mall. Several tablet PCs are used to track
inventory within the establishment. The network administrator decides to use Client Threat Mitigation to
make sure that these tablets are associated only with company-controlled APs.
This scenario uses Client Threat Mitigation rather than the AP De-Authentication Attack for the following
reasons:
• Using AP Mitigation would be difficult because the administrator has no control over APs in adjoining
stores, and keeping up with changes in APs located in other stores might create too much overhead.
• If the administrator were to accidentally classify a neighboring store's AP as Rogue and jam the other
store's traffic, she could potentially be liable for interrupting the business of the adjacent store.
• Employees can be prevented from using the tablet PCs to access public networks for non work-related
functions or to circumvent corporate firewalls, which could expose company data.
To add the clients that are allowed to access the network into the Known Client Database and configure the
Client Threat Mitigation feature:
1. Verify the MAC Authentication mode is white-list on the WLAN > Administration > Advanced
Configuration > Global page.
The white-list authentication mode means that wireless clients with MAC addresses that are specified in
the Known Client database, and are not explicitly denied access, are granted access. If the MAC address is
not in the database then the access to the network is denied.
Note: Radios in non-sentry mode will not transmit Client Threat Mitigation frames. Therefore, sentry
radios must be deployed for the network administrator to use this feature.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
