D-Link DWL-8610AP User Manual

Captive Portal Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 387
D-Link UWS User Manual
Changing the Captive Portal Settings
By default, the switch has one captive portal. You can change the settings for that captive portal, and you can
also create and configure up to nine additional portals. After you create a captive portal from the CP Summary
page, you can change its settings.
Figure 261: Captive Portal Configuration
Table 225 describes the fields on the CP Configuration page.
Protocol Indicates whether the portal uses HTTP or HTTPS.
Verification Specifies which type of user verification to perform:
• Guest: The user does not need to be authenticated by a database.
• Local: The switch uses a local database to authenticated users.
• RADIUS: The switch uses a database on a remote RADIUS server to authenticate
users.
To configure authorized users on the local or remote RADIUS database, see “Local User”
on page 395.
Languages Shows the number of languages that are configured for this captive portal.
Table 225: CP Configuration
Field Description
Enable Captive
Portal
Select the check box to enable the CP. Clear the check box to disable it.
Table 224: Captive Portal Summary (Cont.)
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
