D-Link DWL-8610AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 478
D-Link UWS User Manual
Viewing Distributed Tunneling Information
The AP-AP tunneling mode is used to support L3 roaming for wireless clients without forwarding any data
traffic to the wireless switch.
In the AP-AP tunneling mode, when a client first associates with an AP in the wireless system, the AP forwards
the wireless client’s data using VLAN forwarding mode. The AP the client initially associates with is called the
Home AP. The AP the client roams to is called the Association AP.
Use the menu above the table to select the AP with the distributed tunneling information to view. The AP is
identified by its MAC address and location.
Table 278 describes the fields you see on the Managed Access Point Distributed Tunneling Status page for the
managed access point status.
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Table 278: Distributed Tunneling Status
Field Description
Distributed Tunnel
Clients using AP as
Home
Number of clients that roamed away from this AP using distributed tunneling mode
and are tunneling data back to this AP.
Distributed Tunnel
Clients using AP as
Associate
Number of clients that roamed to this AP using distributed tunneling mode and are
tunneling data to the Home AP.
Distributed Tunnels Number of APs to which this AP has a distributed L2 tunnel. The AP may be acting as
Home AP or Association AP for clients using the tunnel.
Distributed Tunnel
Multicast Replications
Maximum number of tunnels on the Home AP that are members of the same VLAN.
VLAN with Max
Mulitcast Replications
The VLAN ID that is currently replicated the most number of times by the AP for
sending multicasts into distributed tunnels.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
