D-Link DWL-8610AP User Manual

Download File To Switch (TFTP)
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 173
D-Link UWS User Manual
Downloading a File to the Switch
Before you download a switch to the file, the following conditions must be true:
• The file to download from the TFTP server is on the server in the appropriate directory.
• The file is in the correct format.
• The switch has a path to the TFTP server.
Use the following procedures to download a file from a TFTP server to the switch.
1. From the File Type field, select the type of file to download.
2. If you are downloading a D-Link DWS-4000 Series image (Code), select the image on the switch to
overwrite. If you are downloading another type of file, the Image field is not available.
3. Verify the IP address of the TFTP server and ensure that the software image or other file to be downloaded
is available on the TFTP server.
4. Complete the TFTP Server IP Address and TFTP File Name (full path without TFTP server IP address) fields.
5. Click the Start File Transfer check box, and then click Submit.
After you click Submit, the screen refreshes and a “File transfer operation started” message appears. After
the software is downloaded to the device, a message appears indicating that the file transfer operation
completed successfully.
To activate a software image that you download to the switch, see “Multiple Image Service” on page 176.
TFTP File Name Enter the name of the file you want to download from the TFTP server. You
may enter up to 32 characters. The factory default is blank.
Start File Transfer To initiate the download, check this box before clicking Submit.
File Transfer Status Indicates the current status of the file transfer process
Note: It is recommended that you not overwrite the active image.
Table 74: Download File to Switch Fields (Cont.)
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
