D-Link DWL-8610AP User Manual

Port Access Control
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 433
D-Link UWS User Manual
Port Access Privileges
Use the Port Access Control Privileges page to grant or deny port access to users configured on the system.
To access the Port Based Access Control Privileges page, click LAN > Security > Port Access Control > Port
Access Privileges in the navigation menu.
Figure 300: Port Access Privileges
Table 255: Port Access Privileges Fields
Field Description
Port Selects the port to grant or deny access. To grant or deny port access
privileges to a user on all ports, select All from the drop-down menu.
Users Lists the users configured on the system. The users that are highlighted have
access to the selected port. By default, all users have access to all ports. To
deny access to a port, Shift + click to select only the users to allow access.
Make sure the username to deny port access is not selected, and then click
Submit.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
