D-Link DWL-8610AP User Manual

Configuring Advanced Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 602
D-Link UWS User Manual
Wireless Network List
The wireless network list shows all the wireless networks configured on the switch. The first 16 networks are
created by default. You can modify the default networks, but you cannot delete them. You can add and
configure up to 48 additional networks for a total of 64 wireless networks. Multiple networks can have the
same SSID.
Command Buttons
The page includes the following buttons:
• Add — Add a new network. Enter the SSID in the field below the Wireless Network List, and then click
Add. The Wireless Network Configuration page for the new network appears.
• Refresh—Updates the page with the latest information.
• Delete — Delete a network. Select the check box next to the network ID, and then click Delete. You
cannot delete networks 1–16.
Table 352: Wireless Network List
Field Description
ID Shows an automatically generated unique identifier for the network. IDs up to 16 are
assigned to the 16 networks created by default. The switch supports up to 64
networks.
SSID Identifies the name of the network. The SSID is a hyperlink to the Wireless Network
Configuration page for the network.
VLAN Shows the VLAN ID the wireless network uses.
Hide SSID Shows whether the network broadcasts the SSID. If enabled, the SSID for this
network is not included in AP beacons. To change this setting, click Edit.
L3 Tunnel Shows whether L3 Tunneling is enabled on the network.
Note: When L3 tunneling is enabled, the VLAN ID configured above is not used. In
fact, the switch puts the management VLAN ID, if any, on the tunneled packets
destined to the AP.
Security Shows the current security settings for the network.
Redirect Shows whether HTTP redirect is enabled. The possible values for the field are as
follows:
• HTTP: HTTP Redirect is enabled
• None: HTTP Redirect is disabled

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
