D-Link DWL-8610AP User Manual

Configuring Advanced Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 628
D-Link UWS User Manual
Peer Switch Configuration Enable/Disable
You can copy portions of the switch configuration from one switch to another switch in the cluster. The Peer
Switch Configuration Enable/Disable page allows you to select which parts of the configuration to copy to one
or more peer switches in the group.
Figure 393: Peer Switch Configuration Enable/Disable
You can make changes to a configuration that has been sent to one or more peer switches, and you can make
changes to a configuration received from a peer switch. No changes automatically propagate from one switch
to the cluster; you must manually initiate a request on one switch in order to copy any configuration to its
peers.
The following table shows the fields on the detail page for Peer Switch Configuration Enable/Disable page.
Table 360: Peer Switch Configuration Enable/Disable
Field Description
Global Enable this field to include the basic and advanced global settings in the configuration
that the switch pushes to its peers. The configuration does not include the switch IP
address since that is a unique setting.
To view current basic global settings, click the WLAN > Administration > Basic Setup >
Global tab. To view current advanced global settings, click the WLAN > Advanced
Configuration > Global page.
Discovery Enable this field to include the L2 and L3 discovery information, including the VLAN list
and IP list, in the configuration that the switch pushes to its peers.
To view the discovery settings on the local switch, click the WLAN > Administration >
Basic Setup > Discovery tab.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
