D-Link DWL-8610AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 477
D-Link UWS User Manual
The following table describes the fields you see on the VAP TSPEC page.
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Table 277: Managed Access Point VAP TSPEC Status
Field Description
VAP ID The integer ID used to identify the VAP (0-15), this is used to uniquely identify the
VAP for configuration via CLI/SNMP.
Access Category Indicates whether the TSPEC data is for voice traffic or video traffic. The VAP
maintains separate counters for the voice and video categories.
Operational Status Indicates the current operational mode for the category.
The operational mode is influenced by both the individual Admission Control
Mandatory (ACM) mode and overall TSPEC mode.
Number of Active
Traffic Streams
Shows the number of active traffic streams on the selected VAP.
A traffic stream is a collection of data packets identified by the wireless client as
belonging to a particular user priority. An example of a voice traffic stream is a Wi-Fi
Certified telephone handset that marks its codec-generated data packets as voice
priority traffic. An example of a video traffic stream is a video player application on
a wireless laptop that prioritizes a video conference feed from a corporate server.
Number of Traffic
Stream Clients
Shows the number of clients with an active traffic stream on the selected VAP.
Number of Traffic
Stream Roaming
Clients
Shows the number of clients in roaming mode with an active traffic stream on the
selected VAP. This value is also included in the Number of Traffic Stream Clients field.
Medium Time
Admitted
Current sum of medium time (bandwidth) allocated to clients using a traffic stream
on the selected VAP. Medium time is measured in 32 μsec/sec units.
Medium Time
Unallocated
Amount of medium time (bandwidth) not currently allocated for clients connected
through this VAP. Medium time is measured in 32 μsec/sec units.
Medium Time Roaming
Unallocated
Amount of medium time (bandwidth) not currently allocated for roaming clients.
Medium time is measured in 32 μsec/sec units.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
