D-Link DWL-8610AP User Manual

Configuring the Wireless Features
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 437
D-Link UWS User Manual
Section 9: Configuring the Wireless Features
The D-Link Unified Switch is a wireless local area network (WLAN) solution that enables WLAN deployment
while providing state-of-the-art wireless networking features. It is a scalable solution that provides secure
wireless connectivity and seamless layer 2 and layer 3 fast roaming for end users.
This section contains information about the features available in the WLAN folder, which includes the
following:
• Unified Wired and Wireless Access System Components
• Monitoring Status and Statistics
• Basic Setup
• AP Management
• Configuring Advanced Settings
• Configuring the Wireless Distribution System
• Locating WLAN Devices
• Visualizing the Wireless Network
Unified Wired and Wireless Access System Components
The Unified Wired and Wireless Access System components include:
• D-Link DWS-4000 Series Unified Wireless Switch (UWS)
• DWL-8600AP Unified Access Point (UAP)
• DWL-6600AP UAP
• DWL-3600AP UAP
Each DWS-4000 Series switch can manage up to 64 UAPs. Each access point radio can handle up to 200
associated wireless clients, so a dual-radio AP can handle up to 400 wireless clients. The switch tracks the
status and statistics for all associated WLAN traffic and devices.
To support larger networks wireless switches can be configured to belong to a cluster (peer group). Clusters
can contain up to 8 switches that share various information about UAPs and their associated wireless clients.
Each cluster can support up to 256 APs and a total of 8000 wireless clients. Switches within the cluster enable
L3 roaming between managed APs in a routing configuration. This means that wireless clients can roam among
the access points within the cluster without losing network connections. Additionally, you can push portions
of the wireless configuration to one or more switches within the cluster.
One switch in the cluster is automatically elected or configured to be the Cluster Controller. The Cluster
Controller gathers status and statistics about all APs and clients in the cluster so you can view network status
information and manage all devices in the cluster from a single switch.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
