Managing and Viewing Logs
The switch may generate messages in response to events, faults, or errors occurring on the platform as well
as changes in configuration or other occurrences. These messages are stored both locally on the platform and
forwarded to one or more centralized points of collection for monitoring purposes as well as long term archival
storage. Local and remote configuration of the logging capability includes filtering of messages logged or
forwarded based on severity and generating component.
The in-memory log stores messages in memory based upon the settings for message component and severity.
Buffered Log Configuration
The buffered log stores messages in memory based upon the settings for message component and severity.
Use the Buffered Log Configuration page to set the administrative status and behavior of logs in the system
buffer.
To access the Buffered Log Configuration page, click LAN > Administration > Log > Buffered Log Configuration
in the navigation tree.
Figure 41: Buffered Log Configuration
• If you change the buffered log settings, click Submit to apply the changes to the system. To preserve the
changes after a system reboot, you must perform a save.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
