D-Link DWL-8610AP User Manual

Managing the DHCP Server
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 139
D-Link UWS User Manual
Server Statistics
Use the DHCP Server Statistics page to view information about the DHCP server bindings and messages.
To access the Server Statistics page, click LAN > Monitoring > DHCP Server Summary > Server Statistics in the
navigation menu.
Figure 61: Server Statistics
Table 53: Server Statistics Fields
Field Description
Automatic Bindings Shows the number of automatic bindings on the DHCP server.
Expired Bindings Shows the number of expired bindings on the DHCP server.
Malformed Messages Shows the number of the malformed messages.
Message Received
DHCPDISCOVER Shows the number of DHCPDISCOVER messages received by the DHCP server.
DHCPREQUEST Shows the number of DHCPREQUEST messages received by the DHCP server.
DHCPDECLINE Shows the number of DHCPDECLINE messages received by the DHCP server.
DHCPRELEASE Shows the number of DHCPRELEASE messages received by the DHCP server.
DHCPINFORM Shows the number of DHCPINFORM messages received by the DHCP server.
DHCPOFFER Shows the number of DHCPOFFER messages sent by the DHCP server.
DHCPACK Shows the number of DHCPACK messages sent by the DHCP server.
DHCPNAK Shows the number of DHCPNAK messages sent by the DHCP server.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
