D-Link UWS User Manual
Understanding the User Interfaces
D-Link DWS-4000 Series software includes a set of comprehensive management functions for configuring and
monitoring the system by using one of the following three methods:
• Web User Interface
• Command-Line Interface (CLI)
• Simple Network Management Protocol (SNMP)
Each of the standards-based management methods allows you to configure and monitor the components of
the D-Link DWS-4000 Series software. The method you use to manage the system depends on your network
size and requirements, and on your preference.
This guide describes how to use the Web-based interface to manage and monitor the system. For information
about how to manage and monitor the system by using the CLI, see the D-Link DWS-4000 Series CLI Command
Reference.
Using the Web Interface
To access the switch by using a Web browser, the browser must meet the following software requirements:
• HTML version 4.0, or later
• HTTP version 1.1, or later
• JavaScript™ version 1.5, or later
Use the following procedures to log on to the Web Interface:
1. Open a Web browser and enter the IP address of the switch in the Web browser address field.
2. Type the user name and password into the fields on the login screen, and then click Login.
The user name and password are the same as those you use to log on to the command-line interface. By
default, the user name is admin, and there is no password. Passwords are case sensitive.
Note: The switch web UI supports Internet Explorer v6 and v7. Appropriate display of the web pages
is not guaranteed for other web browsers.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
