D-Link DWL-8610AP User Manual

Network DHCP Client Options
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 75
D-Link UWS User Manual
• If you change any of the network connection parameters, click Submit to apply the changes to the system.
If you want the switch to retain the new values across a power cycle, you must perform a save.
Network DHCP Client Options
Use the fields on this page to enable and configure vendor class identifier information that the DHCP client on
the switch sends to the DHCP server when it requests a lease.
To access this page, click LAN > Administration > Network DHCP Client Options.
Locally Administered MAC
Address
You can optionally configure a locally administered MAC address for in-band
connectivity instead of using the burned-in universally administered MAC
address. In addition to entering an address in this field, you must also set the
MAC address type to locally administered. Enter the address as twelve
hexadecimal digits (6 bytes) with a colon between each byte. Bit 1 of byte 0
must be set to a 1 and bit 0 to a 0; i.e., byte 0 must have a value between x'40'
and x'7F'.
MAC Address Type Select the MAC address to use for in-band connectivity. The factory default is
to use the burned-in MAC address.
• Burned-In: Use the factory default MAC address.
• Locally Administered: Use the MAC address you entered in the Locally
Administered MAC Address field.
Management VLAN ID Specifies the management VLAN ID of the switch. The range is 1-3965. The
management VLAN is used for management of the switch. This field is
configurable for administrative users and read-only for other users.
Web Mode Controls whether the switch user interface can be accessed from a Web
browser. The factory default is enabled.
• Enable: Permits Web-based management of the switch.
• Disable: Prohibits Web-based management of the switch. If the Web
mode is disabled, you must manage the switch by using SNMP or the CLI.
Java Mode Controls whether to display the Java applet that displays a picture of the
switch at the top right of the screen. The factory default is enabled:
• Enable: Permits the applet to display. The Java applet lets click on the
picture of the switch to select configuration screens instead of using the
navigation tree at the left side of the screen.
• Disable: Does not allow the Java applet to display. The applet is replaced
by a blank area.
Table 10: Network Connectivity Fields (Cont.)
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
