Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Viewing Detailed Associated Client TSPEC Statistics
The statistics on the TSPEC page show information about each client’s active traffic streams. If there are no
associated clients with active traffic streams, the page displays a message indicating that there are no traffic
streams for any associated clients.
Figure 338: Associated Client Session Detail Statistics
Use the menu above the table to select the MAC address of the client with the information to view. Only clients
with an active traffic stream appear in the selection list.
Fragments Received Total fragmented packets received from the client station.
Fragments Transmitted Total fragmented packets transmitted to the client station.
Transmit Retries Number of times transmits to client station succeeded after one or
more retries.
Transmit Retries Failed Number of times transmits to client station failed after one or more
retries.
TS Violate Packets Received Number of packets sent from a client to the AP in excess of its active
traffic stream (TS) uplink bandwidth, or for an access category
requiring admission control to which the client has not been admitted.
TS Violate Packets Transmitted Number of packets sent from the AP to a client in excess of its active
traffic stream downlink bandwidth, or for an access category requiring
admission control to which the client has not been admitted.
Duplicates Received Total duplicate packets received from the client station.
Note: The client TSPEC statistics do not persist across any client disassociation event, including a
client roam. The TSPEC statistics reset any time a client disassociates from an AP.
Table 305: Associated Client Session Detail Statistics (Cont.)
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
