D-Link DWL-8610AP User Manual

Multiple Image Service
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 176
D-Link UWS User Manual
Uploading Files
Use the following procedures to upload a file from a TFTP server to the switch.
1. From the File Type field, select the type of file to copy from the switch to the TFTP server.
2. If you are uploading a D-Link DWS-4000 Series image (Code), select the image on the switch to upload. If
you are uploading another type of file, the Image Name field is not available.
3. Complete the TFTP Server Address Type, TFTP Server IP Address, and TFTP File Name (full path without
TFTP server IP address) fields.
4. Click the Start File Transfer check box, and then click Submit.
After you click Submit, the screen refreshes and a “File transfer operation started” message appears. After
the software is downloaded to the device, a message appears indicating that the file transfer operation
completed successfully.
Multiple Image Service
The system maintains two versions of the D-Link DWS-4000 Series software in permanent storage. One image
is the active image, and the second image is the backup image. The active image is loaded during subsequent
switch restarts. This feature reduces switch down time when upgrading/downgrading the D-Link DWS-4000
Series software.
The system running an older software version will ignore (not load) a configuration file created by the newer
software version. When a configuration file created by the newer software version is discovered by the system
running an older version of the software, the system will display an appropriate warning to the user.
Use the Multiple Image Service page to set the boot image.
To display the Multiple Image Service page, click Tool > Multiple Image Service in the navigation menu.
TFTP File Path Enter the path on the TFTP server where you want to put the file. You may
enter up to 32 characters. The factory default is blank.
TFTP File Name Enter a destination file name for the file to upload. You may enter up to 32
characters. The factory default is blank.
Start File Transfer To initiate the file upload, check this box before clicking Submit.
File Transfer Status Indicates the current status of the file transfer process
Table 76: Upload File from Switch Fields (Cont.)
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
