Command Buttons
The page includes the following buttons:
• Delete All—Deletes all ad hoc client entries from the list. Clearing the list does not disassociate any of the
ad hoc clients, and the clients might still be involved in the ad hoc network.
• Deny—Blocks an ad hoc client from WLAN access. The MAC address is added to the Known Client
database where the default action is Deny.
• Allow—Allows an ad hoc client access to the WLAN. The MAC address is added to the Known Client
database where the default action is Allow.
• Refresh—Updates the page with the latest information.
Detected Client Status
Wireless clients are detected by the wireless system when the clients either attempt to interact with the
system or when the system detects traffic from the clients. The Detected Client Status page contains
information about clients that have authenticated with an AP as well information about clients that
disassociate and are no longer connected to the system. To access the page click WLAN > Monitoring > Client
> Detected Clients.
The Cluster Controller receives information about associated clients from all switches in the cluster, and you
can disassociate clients on any AP in the cluster from the Cluster Controller.
Table 307: Ad Hoc Client Status
Field Description
MAC Address The Ethernet address of the client. If the Detection Mode is Beacon then the client is
represented as an AP in the RF Scan database and the Neighbor AP List. If the
Detection Mode is Data Frame then the client information is in the Neighbor Client
List.
AP MAC Address The base Ethernet MAC Address of the managed AP which detected the client.
Location The configured descriptive location for the managed AP.
Radio The radio interface and its configured mode that detected the ad hoc device.
Detection Mode The mechanism of detecting this Ad Hoc device. The possible values are Beacon
Frame or Data Frame.
Age Time since last detection of the ad hoc network.
Note: If the Deny button is not available, it means all profiles use Allow as the default MAC
Authentication action. Likewise, if the Allow button is not available, no profiles have an Allow default
action.
Note: If you use RADIUS for MAC authentication in one or more AP profiles, you must add the MAC
Address of the client to the RADIUS database.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
