D-Link DWL-8610AP User Manual

About This Document
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 45
D-Link UWS User Manual
About This Document
This guide describes how to configure the D-Link DWS-4000 Series Unified Wireless Switch (UWS) software
features by using the Web-based graphical user interface (GUI). The Unified Wired and Wireless Access System
architecture accommodates a variety of software modules, so D-Link DWS-4000 Series can be a Layer 2 switch
in a basic network or a Layer 3 router in a large, complex network. The switch software includes WLAN features
that allow it to manage and monitor multiple D-Link DWL-x600AP Access Points.
Audience
The information in this guide is intended for any of the following individuals:
• System administrators who are responsible for configuring and operating a network using D-Link DWS-
4000 Series switch
• Level 1 and/or Level 2 Support providers
To obtain the greatest benefit from this guide, you should have an understanding of the base software and
should have read the specification for your networking device platform. You should also have basic knowledge
of Ethernet and networking concepts.
Organization
This guide contains the following sections:
• Section 1: “Getting Started,” on page 47contains information about performing the initial system
configuration and accessing the user interfaces.
• Section 2: “System Administration,” on page 62 describes how to configure administrative features such
as SNMP, DHCP, and port information.
• Section 3: “Using System Tools,” on page 169 describes how to perform the system-maintenance tasks
available from the Tools menu.
• Section 4: “Configuring L2 Features,” on page 181 describes how to manage and monitor the layer 2
switching features.
• Section 5: “Configuring L3 Features,” on page 280 describes how to configure the layer 3 routing features.
• Section 6: “Configuring Quality of Service,” on page 334 describes how to configure the Differentiated
Services, Class of Service, and Auto VoIP features.
• Section 7: “Configuring Access Control Lists,” on page 356 describes how to manage the D-Link DWS-4000
Series software ACLs.
• Section 8: “Managing Device Security,” on page 373 contains information about configuring switch
security information such as captive portal configuration, port access control, TACACS+, and RADIUS
server settings.
• Section 9: “Configuring the Wireless Features,” on page 437describes how to configure the switch so it
can manage multiple access points on the network.
• Appendix A: “Configuration Examples,” on page 679 describe how to configure selected features on the
switch by using the Web interface, command-line interface, and Simple Network Management Protocol
(SNMP).

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
