Managing the DHCP Server
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 140
D-Link UWS User Manual
• Click Refresh to update the information on the screen.
• Click Clear Server Statistics to reset all counters to zero.
Conflicts Information
Use the Conflicts Information page to view information on hosts that have address conflicts; i.e., when the
same IP address is assigned to two or more devices on the network.
To access the Conflicts Information page, click LAN > Monitoring > DHCP Server Summary > Conflicts
Information in the navigation tree.
Figure 62: Conflicts Information
Table 54: Conflicts Information Fields
Field Description
DHCP Conflicts Select the DHCP conflicts to display:
• All Conflicts: Show all conflicts.
• Specific Conflict: Show a specific conflict. When you select this option, the
screen refreshes, and the Conflict IP Address field appears.
Conflict IP Address Specify the IP address for which you want to view conflict information. This
field is only available if you select Specific Conflicts from the DHCP Conflict
field.
IP Address Displays the client IP address.
Detection Method Specifies the manner in which the IP address of the hosts were found on the
DHCP server.
Detection Time Specifies the time when the conflict was detected in N days NNh:NNm:NNs
format with respect to the system up time.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
