D-Link DWL-8610AP User Manual

ACL Interface Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 372
D-Link UWS User Manual
Assigning an ACL to an Interface
1. Open the ACL Interface Configuration page.
2. Select the interface from the Slot/Port field to which you want to bind the ACL.
3. Select the type of ACL in the ACL Type field.
4. Select the ACL ID or name to bind to the interface.
5. Specify the priority in the Sequence field.
6. Click Submit.
The ACL is attached to the specified interface(s).
Removing an ACL from an Interface
If an ACL is bound to an interface, the Remove button appears on the page when you select the interface from
the Slot/Port menu. To remove the ACL from the interface, select the type of ACL to remove and its ID or name,
and then click Remove.
Note: Whenever an ACL is assigned on a port or LAG, flows from that ingress interface that do not
match the ACL are matched to the default rule, which is Drop unmatched packets.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
