D-Link DWL-8610AP User Manual

Configuration Examples
D-Link Unified Wired and Wireless Access System
July 2012 Page 679
D-Link UWS User Manual
Appendix A: Configuration Examples
This appendix contains examples of how to configure selected features available in the Unified Wired and
Wireless Access System software. Each example contains procedures on how to configure the feature by using
the Web interface, CLI, and SNMP.
This appendix describes how to perform the following procedures:
• Configuring VLANs
• Configuring VLAN Routing
• Configuring Multiple Spanning Tree Protocol
• Configuring a Virtual Access Point
• Configuring Differentiated Services for VoIP
• Configuring a Network with WDS-Managed APs
• Configuring a Network to Use WPA2-Enterprise and Dynamic VLANs
• Optimizing WLAN Traffic
• Detecting and Preventing Wireless Intrusion
Configuring VLANs
The diagram in this section shows a switch with four ports configured to handle the traffic for two VLANs. Port
0/2 handles traffic for both VLANs, while port 0/1 is a member of VLAN 2 only, and ports 0/3 and 0/4 are
members of VLAN 3 only.
The following examples show how to create VLANs, assign ports to the VLANs, and assign a VLAN as the default
VLAN to a port.
Note: Each configuration example starts from a factory-default configuration unless otherwise noted.
