D-Link DWL-8610AP User Manual

Basic Setup
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 567
D-Link UWS User Manual
If you select WPA/WPA2 as the security mode, additional fields display, as the following figure shows.
Figure 364: WPA Personal Configuration
The following table describes the configuration options for the WPA Personal and WPA Enterprise security
mode.
Table 332: WPA Security
Field Description
WPA Personal or WPA
Enterprise
WPA/WPA2 Personal uses static key management. You manually configure the
same keys to encrypt data on both the wireless client and the AP. WPA/WPA2
Enterprise uses a RADIUS server and dynamically generated keys to encrypt client-
to- AP traffic. WPA Enterprise is more secure than WPA Personal, but you need a
RADIUS server to manage the keys.
If you select WPA Enterprise, the screen refreshes, and the WPA Key Type and WPA
Key fields are hidden. The AP uses the global RADIUS server or the RADIUS server
you specify for the wireless network
For information about how to configure the global RADIUS server settings on the
DWS-4000 Series switch, see “Wireless Global Configuration” on page 539.
WPA Versions Select the types of client stations you want to support:
• WPA: If all client stations on the network support the original WPA but none
support the newer WPA2, then select WPA.
• WPA2: If all client stations on the network support WPA2, D-Link suggests using
WPA2 which provides the best security per the IEEE 802.11i standard.
• WPA and WPA2: If you have a mix of clients, some of which support WPA2 and
others which support only the original WPA, select both of the boxes. This lets
both WPA and WPA2 client stations associate and authenticate, but uses the
more robust WPA2 for clients who support it. This WPA configuration allows
more interoperability, at the expense of some security.
WPA Ciphers Select the cipher suite you want to use:
• TKIP
• CCMP (AES)
• TKIP and CCMP (AES)
Both TKIP and AES clients can associate with the access point. WPA clients must
have one of the following to be able to associate with the AP:
• A valid TKIP key
• A valid AES-CCMP key
Note: The 802.11n clients cannot use the TKIP cipher. Therefore if only TKIP is
enabled then the 802.11 clients will not be able to authenticate with the network.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
