D-Link DWL-8610AP User Manual

Configuring Dynamic ARP Inspection
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 277
D-Link UWS User Manual
DAI ARP ACL Configuration
Use the DAI ARP ACL Configuration page to add or remove DAI ARP ACLs.
To display the DAI ARP ACL Configuration page, click LAN > L2 Features>Dynamic ARP Inspection > DAI ARP
ACL Configuration in the navigation tree.
Figure 174: Dynamic ARP Inspection ARP ACL Configuration
• Click Add to create a new ARP ACL.
• Click Delete to remove the configured ARP ACL entry you selected in the Remove column.
• Click Refresh to refresh the page with the most current data from the switch.
Table 157: Dynamic ARP Inspection ARP ACL Configuration
Field Description
ARP ACL Name Use this field to create a new ARP ACL for Dynamic ARP Inspection. The name can be 1 to
31 alphanumeric characters in length.
ARP ACL List Displays by name a list of all the configured ARP ACLs. Use the Remove column, to select
the particular ACLs you want to delete.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
