D-Link DWL-8610AP User Manual

Configuring DNS
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 147
D-Link UWS User Manual
DNS Host Name IP Mapping Configuration
Use this page to configure DNS host names for hosts on the network. The host names are associated with IPv4
or IPv6 addresses on the network, which are statically assigned to particular hosts.
To access this page, click LAN > Administration > DNS Client > HostName IP Mapping in the navigation tree,
then click the Add Static Entry button.
Figure 68: DNS Host Name Mapping Configuration
• Click Submit to apply the new configuration and cause the change to take effect immediately. These
changes will not be retained across a power cycle unless a Save is performed.
• Click Back to cancel and display the hostname IP mapping page to see the configured hostname-IP
mapping entries.
Table 60: DNS Host Name Mapping Configuration Fields
Field Description
Host Name Enter the host name to assign to the static entry.
Inet Address Enter the IP4 or IPv6 address associated with the host name.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
