D-Link DWL-8610AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 523
D-Link UWS User Manual
Viewing Detected Client Pre-Authentication History
To help authenticated clients roam without losing sessions and needing to re-authenticate, wireless clients can
attempt to authenticate to other APs within range that the client could possibly associate with. For successful
pre-authentication, the target AP must have a VAP with an SSID and security configuration that matches that
of the client, including MAC authentication, encryption method, and pre-shared key or RADIUS parameters.
The the AP that the client is associated with captures all pre-authentication requests and sends them to the
switch.
The Detected Client Pre-Authentication History page shows information about the pre-authentication
requests that the detected client has made.
Figure 343: Detected Client Pre-Authentication History
Table 311 describes the fields on the Detected Client Pre-Authentication History page.
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Table 311: Detected Client Pre-Authentication History
Field Description
MAC Address MAC address of the client.
AP MAC Address MAC Address of the managed AP to which the client has pre-authenticated.
Radio Interface
Number
Radio number to which the client is authenticated, which is either Radio 1 or Radio 2.
VAP MAC Address VAP MAC address to which the client roamed.
SSID SSID Name used by the VAP.
Age Time since the history entry was added.
User Name Indicates the user name of client that authenticated via 802.1X.
Pre-Authentication
Status
Indicates whether the client successfully authenticated and shows a status of
Success or Failure.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
