D-Link DWL-8610AP User Manual

Configuring Advanced Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 630
D-Link UWS User Manual
Mutual Authentication
Mutual Authentication provides security when adding switches and APs to the wireless network. If Mutual
Authentication mode is enabled, the APs and switches perform X.509 Mutual Certificate exchanges. Each
device compares the certificate received from the remote end-point with the local copy of the remote device's
certificate. If the certificates don't match then the Transport Layer Security (TLS) connection is dropped.
Figure 394: Mutual Authentication
The following table shows the fields on the Mutual Authentication page.
Command Buttons
The page includes the following buttons:
• Submit—Updates the switch with the values you enter. To retain the new values across a power cycle,
you must perform a save (Tool > Save Changes).
• Refresh—Updates the page with the latest information.
Table 361: Mutual Authentication
Field Description
Switch Provisioning Mode When this field is enabled, switches can send and receive provisioning messages.
As a security feature, you can disable switch provisioning. When switch
provisioning mode is disabled the switch does not accept provisioning messages.
Network Mutual
Authentication Mode
Select Enable to require mutual authentication on the wireless network. When
Disable is selected, mutual authentication is not required.
Changing this parameter on one switch automatically updates the configuration
on all other switches in the cluster and all managed APs in the cluster.
When this field is enabled, switch provisioning must be enabled in order for new
switches to be added to the cluster. If switch provisioning is disabled, the cluster
will not accept certificates from a new switch.
Unmanaged AP
Reprovisioning Mode
When this field is enabled, the AP can be re-provisioned when it is not managed.
Changing this parameter on one switch automatically updates the configuration
on all other switches. This parameter is only applicable if mutual authentication
is enabled.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
