Visualizing the Wireless Network
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 676
D-Link UWS User Manual
The following figure identifies the toolbar icons directly below the menu bar.
Figure 429: Toolbar Icons
Locate
Target Access Point Select this option to allow the wireless system to search for an AP and
update its location based on the received search information.
When you select this option, a window opens that allows you to select the
MAC address of the AP to search for and to specify the location search
parameters.
Target Client Select this option to allow the wireless system to search for a client and
update its location based on the received search information.
When you select this option, a window opens that allows you to select the
MAC address of the client to search for and to specify the location search
parameters.
Legend
Images Shows the icons associated with each WLAN component on the graph.
Channel Color Maps the color of the power transmission image to the channel that the
radio is using for transmission.
Help
Help Opens a new HTML window to display the WLAN Visualization online help
page.
Table 386: WLAN Visualization Menu Bar Options (Cont.)
Menu Item Description
Live Visualization ControlDefault Image Size
Zoom Out Zoom In Force Refresh

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
