D-Link DWL-8610AP User Manual

Telnet Sessions
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 92
D-Link UWS User Manual
Removing or Modifying a Port Mirroring Session
1. From the Port Mirroring page, click Remove Source Port.
2. Select one or more source ports to remove from the session.
Use the CTRL key to select multiple ports to remove.
3. Click Remove.
The source ports are removed from the port mirroring session, and the device is updated.
Telnet Sessions
Telnet is a terminal emulation TCP/IP protocol. ASCII terminals can be virtually connected to the local device
through a TCP/IP protocol network. Telnet is an alternative to a local login terminal where a remote login is
required.
The switch supports up to five simultaneous telnet sessions. All CLI commands can be used over a telnet
session.
The Telnet Session Configuration page allows you to control inbound telnet settings on the switch. Inbound
telnet sessions originate on a remote system and allow a user on that system to connect to the switch CLI. To
configure outbound telnet settings, which are telnet sessions that originate on the switch to access a remote
system, see “Outbound Telnet Client Configuration” on page 94.
To display the Telnet Session Configuration page, click LAN > Administration > Telnet Session in the navigation
tree.
Figure 26: Telnet Session Configuration

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
