D-Link DWL-8610AP User Manual

Configuring and Viewing ISDP Information
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 150
D-Link UWS User Manual
Cache Table
From the ISDP Cache Table page, you can view information about other devices the switch has discovered
through the ISDP. To access the ISDP Cache Table page, click LAN > Monitoring > ISDP > Cache Table in the
navigation menu.
Figure 71: ISDP Cache Table
The following table describes the fields available on the ISDP Cache Table page.
Device ID Format
Capability
Indicates the Device ID format capability of the device.
• serialNumber—Indicates that the device uses serial number as the format for its
Device ID.
• macAddress—Indicates that the device uses layer 2 MAC address as the format for
its Device ID.
• other—Indicates that the device uses its platform specific format as the format for
its Device ID.
Device ID Format Indicates the Device ID format of the device.
• serialNumber—Indicates that the value is in the form of an ASCII string containing
the device serial number.
• macAddress—Indicates that the value is in the form of Layer 2 MAC address.
• other—Indicates that the value is in the form of a platform specific ASCII string
containing info that identifies the device. For example: ASCII string contains
serialNumber appended/prepended with system name.
Table 63: ISDP Cache Table
Field Description
Device ID Displays the string with Device ID which is reported in the most recent ISDP
message.
Interface Displays the interface that this neighbor is attached to.
IP Address The (first) network-layer address that is reported in the Address TLV of the
most recently received ISDP message.
Version Displays the Version string for the neighbor.
Table 62: ISDP Global Configuration
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
