D-Link DWL-8610AP User Manual

Configuring GARP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 206
D-Link UWS User Manual
GARP Switch Configuration
Use the GARP Switch Configuration page to configure GARP settings for the system.
To access the GARP Switch Configuration page, click LAN > L2 Features> GARP > Switch Configuration in the
navigation tree.
Figure 115: GARP Switch Configuration
• If you make any changes to the page, click Submit to apply the changes to the system.
Table 99: GARP Switch Configuration Fields
Field Description
Switch GVRP Mode Shows the GARP VLAN Registration Protocol administrative mode for the
switch. The switch GVRP mode must be enabled for the ports to function in
GARP protocols, even if GVRP is enabled on a port.
Switch GMRP Mode Shows the GARP Multicast Registration Protocol administrative mode for the
switch. The switch GMRP mode must be enabled for the ports to function in
GARP protocols, even if GMRP is enabled on a port.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
