D-Link DWL-8610AP User Manual

Ping Test
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 95
D-Link UWS User Manual
Ping Test
Use the Ping page to tell the switch to send a Ping request to a specified IP address. You can use this feature
to check whether the switch can communicate with a particular network host.
To access the Ping page, click LAN > Administration > Ping Test in the navigation menu.
Figure 28: Ping
• Click Submit to send the ping. If successful, the results display as shown in Figure 29.
Table 23: Ping Fields
Field Description
Hostname/IP Address Enter the IP address or the host name of the station you want the switch to
ping. The initial value is blank. This information is not retained across a power
cycle.
Count Specify the number of pings to send.
Interval Specify the number of seconds between pings sent.
Size Specify the size of the ping packet to send.
Ping Displays the results of the ping.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
